Processors
Specification
|
Description
|
Intel Core i7-7700 processor
|
65 W
Up to 4.2 GHz maximum Turbo Frequency (3.6 GHz base frequency)
8 MB cache, 4 cores, 8 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
Memory
Specification
|
Description
|
DDR4-2400
|
Maximum: 32 GB
Number of slots: (2) DIMM (both slots are customer accessible/upgradeable)
Up to 2400 MT/s
|
Configurations
|
16384 MB total system memory (8192 MB x 2)
|
Ports/slots/bays
Specification
|
Description
|
Ports
|
Standard
(4) USB 2.0: rear
(4) USB 3.1: (2) front, (2) rear
PS/2: optional
(1) DisplayPort
(1) VGA
(1) Headset, front
(1) Audio line-in, rear
(1) Audio line-out, rear
(1) RJ-45 Ethernet
Optional
(1) Serial (RS-232) and PS/2 combination (rear)
Internal
(3) Internal SATA storage connectors
|
Expansion slots
|
(1) PCI Express x1 (v3.0)
6.35 cm (4.2 in) full height
16.76 cm (6.6 in) length
35 W maximum power
(2) PCI Express x16 (v3.0); 1 wired as an x4
6.35 cm (4.2 in) full height
16.76 cm (6.6 in) length
35 W maximum power
(1) Turbo Drive (M.2 PCIe)
(1) M.2 PCIe x1-2230 (for WLAN)
|
Bays
|
(1) 0.9 cm (0.35 in) Slim optical disc drive (ODD)
(1) 6.35 cm (2.5 in) internal storage drive
(1) 8.89 cm (3.5 in) internal storage drive
(2) Secure Digital (SD) 3 reader
|
